PRO1 T855iSH Universal - WiFi
PRO1 T855iSH Universal - WiFi

PRO1 T855iSH Universal - WiFi

(No reviews) Write a Review

Log in for pricing

SKU: PRO1-WIFI-T855iSH
UPC: 095247201662
Download Spec Sheet PDF

Ask An Expert

Bobby Caffrey

Call (816) 643-3875 >

Send Email >

  • System Design & Layout

    Engineering and temperature analysis

  • Equipment Selection Guidance

    Get the best product for your facility

  • Maintenance Support

    We'll be there if you need us, 24/7/365.

  • Fast Support

    Our team is only a phone call away.

Description

T800 Platform: WIFI enabled, programmable, universal, 5H/3C, humidify and de-humidify, 8 sq. in. display. Compatible with R251S, or R250S, (sold separately)
Specifications
Model WIFI
Model Number T855iSH
Application Up to 2 heat, 3 cool conventional / Up to 5 heat, 3 cool heat pump
MODEL FEATURES • 16 Remote sensor capable • 8 sq. inch display • Blue backlight • Glow in the dark light button • Two and four occupancy/unoccupancy time periods available • Partial and full keypad lockout • Adjustable setpoint limits • Summer away mode •...
PROGRAMMABILITY 7 day, 5/1/1 or Non-programmable
CHANGEOVER System Switch
DISPLAY RANGE 41˚F to 95˚F (5˚C to 35˚C)
CONTROL RANGE 44˚F to 90˚F (7˚C to 32˚C)
DISPLAY ACCURACY +/- 1˚F
HEAT SWING Adjustable from 0.2˚F to 2.0˚F
COOL SWING Adjustable from 0.2˚F to 2.0˚F
TERMINALS Rc, Rh, G, Y, Y2, S1, S2, C , O, B, W/E, W2
LOAD RATING 1 amp per terminal, 1.5 amp maximum all terminals combined
POWER SOURCE 18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire)
OPERATING AMBIENT 32°F to +105°F (0°C to +41°C)
OPERATING HUMIDITY 90% non-condensing maximum
MOUNTING Wall or Junction Box
DIMENSIONS 4.7”W x 4.4”H x 1.1”D (119mm W x 112mm H x 28mm D)
!
